| EU RoHS |
Compliant with Exemption |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| HTS |
8533.29.00.00 |
| Resistance Value (Ohm) |
500m |
| Tolerance |
5% |
| Maximum Voltage Rating (V) |
250 |
| Current Sensing |
No |
| Power Rating (W) |
35 |
| Technology |
Thick Film |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
155 |
| Temperature Coefficient (ppm/°C) |
±100 |
| Temperature Range @ Derated Power (°C) |
25 to 155 |
| Fail Safe Fusible Resistor |
No |
| Anti-Surge |
No |
| Anti-Sulfurated |
No |
| Case Style |
Epoxy |
| Termination Style |
Gull Wing |
| Number of Terminals |
2 |
| Terminal Pitch (mm) |
5.08 |
| Packaging |
Tube |
| Package Type |
TO-263 |
| Package Shape |
Rectangular |
| Package/Case |
TO-263 |
| Product Length (mm) |
10.1 |
| Product Depth (mm) |
15.39 |
| Product Height (mm) |
4.5 |
| Mounting |
Surface Mount |
