Product Features Product Technical Specifications EU RoHS Compliant ECCN (US) EAR99 Part Status Active Automotive No PPAP No Military Standard MIL-DTL-38999 Military Standard Series Series II Type Circular Gender RCP Mounting Box Mount Body Orientation Straight Polarization N Number of Ports 1 Number of Contacts 22 Number of Terminals 22 Contact Gender PIN Termination Method Crimp Shell Size / Insert Arrangement 12-35 Wire Size (AWG) 22-28 Less Contact No Contact Material Copper Alloy Contact Plating Gold Shell Material Stainless Steel Shell Plating Electroless Nickel Minimum Operating Temperature (°C) -65 Maximum Operating Temperature (°C) 200 Mating Style Bayonet Lock Mating Cycle (Cycles) 500 Product Length (mm) 17.7 Product Depth (mm) 26.59 Product Height (mm) 26.59 -
