EU RoHS |
Not Compliant
|
|
ECCN (US) |
EAR99 |
|
Part Status |
Active |
|
SVHC |
Yes |
|
SVHC Exceeds Threshold |
Yes |
|
Military Standard |
MIL-DTL-38999 |
|
Military Standard Series |
Series III |
|
Type |
Circular |
|
Gender |
RCP |
|
Mounting |
Jam Nut |
|
Body Orientation |
Straight |
|
Polarization |
N |
|
Number of Ports |
1 |
|
Number of Contacts |
19 |
|
Number of Terminals |
19 |
|
Contact Gender |
SKT |
|
Termination Method |
Crimp |
|
Shell Size / Insert Arrangement |
15-19 |
|
Wire Size (AWG) |
20-24 |
|
Less Contact |
No |
|
Contact Material |
Copper Alloy |
|
Contact Plating |
Gold Over Nickel |
|
Shell Material |
Aluminum |
|
Shell Plating |
Cadmium |
|
Housing Color |
Olive Drab |
|
Maximum Current Rating (A) |
7.5 |
|
Product Weight (g) |
37.89 |
|
Minimum Operating Temperature (°C) |
-65 |
|
Maximum Operating Temperature (°C) |
175 |
|
IP Rating |
IP67 |
|
Insulation Resistance (MOhm) |
5000 |
|
Maximum Contact Resistance (mOhm) |
7.3 |
|
Mating Style |
Screw Lock |
|
Mating Cycle (Cycles) |
500 |
|
Product Diameter (mm) |
41.6 |
|
Product Length (mm) |
32.5 |
|
Product Depth (mm) |
38.1 |
|
Product Height (mm) |
