EU RoHS |
Compliant with Exemption
|
|
ECCN (US) |
EAR99 |
|
Part Status |
Active |
|
HTS |
8533.21.00.30 |
|
Automotive |
Yes |
|
PPAP |
Yes |
|
Resistance Value (Ohm) |
330 |
|
Tolerance |
1% |
|
Maximum Voltage Rating (V) |
500 |
|
Current Sensing |
No |
|
Power Rating (W) |
1 |
|
Technology |
Thick Film |
|
Minimum Operating Temperature (°C) |
-55 |
|
Maximum Operating Temperature (°C) |
155 |
|
Temperature Coefficient (ppm/°C) |
±100 |
|
Temperature Range @ Derated Power (°C) |
70 to 155 |
|
Special Features |
High Reliability|High Stability |
|
Fail Safe Fusible Resistor |
No |
|
Anti-Surge |
No |
|
Anti-Sulfurated |
No |
|
Case Style |
Conformal Coated |
|
Case Size |
2512 |
|
Termination Style |
Pad |
|
Number of Terminals |
2 |
|
Packaging |
Tape and Reel |
|
Package Type |
SMD |
|
Package Shape |
Rectangular |
|
Package/Case |
2512 |
|
Product Length (mm) |
6.3 |
|
Product Depth (mm) |
3.15 |
|
Product Height (mm) |
0.6 |
|
Product Weight (g) |
0.0405 |
|
Length Tolerance (mm) |
±0.2 |
|
Depth Tolerance (mm) |
±0.15 |
|
Height Tolerance (mm) |
±0.1 |
|
Mounting |
Surface Mount |
