| EU RoHS |
Compliant with Exemption |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| HTS |
8533.21.00.30 |
| Resistance Value (Ohm) |
59 |
| Tolerance |
1% |
| Maximum Voltage Rating (V) |
200 |
| Current Sensing |
No |
| Power Rating (W) |
0.25 (1/4) |
| Technology |
Thick Film |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
155 |
| Temperature Coefficient (ppm/°C) |
±100 |
| Temperature Range @ Derated Power (°C) |
70 to 155 |
| Fail Safe Fusible Resistor |
No |
| Anti-Surge |
No |
| Anti-Sulfurated |
No |
| Case Style |
Conformal Coated |
| Case Size |
1206 |
| Termination Style |
Pad |
| Number of Terminals |
2 |
| Packaging |
Tape and Reel |
| Package Type |
SMD |
| Package Shape |
Rectangular |
| Package/Case |
1206 |
| Product Length (mm) |
3.2 |
| Product Depth (mm) |
1.6 |
| Product Height (mm) |
0.55 |
| Product Weight (g) |
0.01 |
| Length Tolerance (mm) |
+0.1|-0.2 |
| Depth Tolerance (mm) |
±0.15 |
| Height Tolerance (mm) |
±0.05 |
| Mounting |
Surface Mount |
