CDRH4D28NP-2R2NC Sumida | Partsmax Türkiye

Product Features

Product Technical Specifications

EU RoHS Compliant
ECCN (US) EAR99
Part Status Active
HTS 8504.50.80.00
SVHC Yes
Automotive No
PPAP No
Type Power
Technology Drum Core
Protection Style Shielded
Core Material Ferrite
Inductance (H) 2.2u
Inductance Decrease Percentage @ Isat (%) 65
Tolerance 30%
Inductance Test Frequency (Hz) 100K
Maximum DC Current (A) 2.04
Maximum Saturation Current (A) 2.04
Maximum DC Resistance (Ohm) 0.0313
Number of Terminals 2
Minimum Operating Temperature (°C) -40
Maximum Operating Temperature (°C) 100
Packaging Tape and Reel
Product Length (mm) 5
Mounting Surface Mount
Product Depth (mm) 5
Product Height (mm) 3
Additional Resources
ATTRIBUTE DESCRIPTION
Other Names
308-2305-1
308-2305-2
CDRH4D28NP-2R2NCTR
308-2305-6
CDRH4D28NP-2R2NCTR-ND
