| EU RoHS |
Compliant |
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| HTS |
8536.41.00.60 |
| Type |
Open Loop |
| Module/IC Classification |
IC |
| Sensing Current Type |
AC|DC |
| Typical RMS Primary Current (A) |
±15 |
| Accuracy (%) |
±1.6 |
| Typical Response Time (us) |
4 |
| Minimum Operating Supply Voltage (V) |
4.5 |
| Typical Operating Supply Voltage (V) |
5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Sensitivity (mV/A) |
90 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Packaging |
Tape and Reel |
| Supplier Package |
SOIC W |
| Pin Count |
16 |
| Standard Package Name |
SOP |
| Mounting |
Surface Mount |
| Package Height |
2.35(Max) |
| Package Length |
10.3 |
| Package Width |
7.5 |
| PCB changed |
16 |
