Product Features Product Technical Specifications EU RoHS Compliant ECCN (US) EAR99 Part Status Active HTS 8536.50.90.65 Actuator Style Locking Lever Pole Throw Configuration SPDT Switch Configuration ON ON Bushing Type Threaded Maximum Current Rating (A) 20@28VDC Actuator Length (mm) 26.7 Mounting Panel Mount with Threads Termination Style Screw Number of Terminals 3 Terminal Length (mm) 3.3 Seal Complete Seal Description Complete Body Orientation Straight Minimum Operating Temperature (°C) -65 Maximum Operating Temperature (°C) 71 Thread Size 15/32-32 Body Length (mm) 28.4 Bushing Length (mm) 11.9 Body Depth (mm) 15.7 Body Height (mm) 34.3 Product Length (mm) 28.4 Product Depth (mm) 15.7 Product Height (mm) 72.9
